1. 600-24S12 isolated DC-DC power module, continuous input of 16-40Vdc, transient input 50V@1s 12Vdc output, output power 600W; Standard 1/2 brick, with a fully enclosed five sided metal structure; High reliability

High efficiency, high power density, low ripple noise, and other characteristics; Widely used in military, communication, rail transit and other fields.

2. Positive/negative logic control optional

3. Rated output power: 600W

4. Output overcurrent and short circuit protection

5. Input undervoltage protection

6. Output overvoltage protection

7. Over temperature protection

8. Built-in output fault isolation (built-in ORing circuit)

9. Supporting module parallel connection

10. Working shell temperature: -40 ℃~105 ℃

11. Input and output dielectric strength: 2250Vdc

12、MTBF ≥ 2,000,000h

RoHS5
